CMAX Ultimate 79 Leaf Spring Kit

** This Kit uses standard 79mm leaf spring spacing for the front and rear axles. This kit does not fit front TMX axle narrow leaf spacing (66mm). Please use the 'Yota 152 Kit' for TMX Leaf springs. **

Are you ready for a new All Leaf Sprung Scale truck build? Here's a really solid setup ready to accept your build and completion. Our new CMAX Combo Kit will let you start a scale represented RC Model build with a full ladder frame, C-channel design, with a Steel geared scale driveline and transfer case, along with EPIC amounts of adjustment.
We've set up this rail set to allow the drivetrain to slide forward and aft a total of over 30mm. The front servo mount adjustment is another 20mm, so you can match up your body and equipment alignment perfectly with NO strength compromise or extra parts.
The Leaf spring hanger sets using Tamiya 9808091 springs can adjust wheelbases from 260mm up to 368mm on this chassis. The rear leaf spring swing hanger contains a bushing for solid mounting and easy articulation during the travel.
CMAX leaf spring spacing fits all the major axle sets on the market, from RC4wd as well as GCM and others.

Scale Motors are available to slide over your 540 size motor Here at this link.
Body and bumper and battery mount options available at our GCM Racing ShapeWays store Here at this link.

This CMAX Ultimate Leaf Spring Kit includes all the essence of a Leaf Sprung Scale Truck build. In your package you'll find the following items:

Left and Right Chassis Rails, 19.7 inches long
Front Servo Mount
Front Shock Mounts
Front Leaf Spring mount, and swing hanger
Front 540 size Motor Mount Plate
GCM LowRange Scale Transmission, Steel Gear, 14.3 Gear Ratio
LRT2 Transfer Case, 1.11 Overdrive Front Output
Transfer Case Cross Member
Frame Center Cross Member
Frame Rear Cross Member/Rear Shock Mount
Rear Leaf Spring mount, and swing hanger
Includes All Hex Hardware, 12t Pinion Gear for 1/8 motor shaft, All steel drivetrain gears and shafts, and all aluminum mounts and rails.

Our Favorites for this build:

1. We recommend ECX213000 shocks for this kit, which provide the perfect amount of travel, don't leak, and are already filled with oil. Simply remove the coil spring and spring seats, and install on the truck. Very nice little shocks.
2. We recommend Tamiya spring #9808091 for all 4 springs. Tamiya helper springs are available in part number group #58372
